ITAWATT Force A261 (DC)
ITAWATT Force A261 (DC)
Features
High-Capacity Energy Storage
With 261 kWh of rated energy, the FORCE A261 supports demanding commercial and industrial applications that require substantial and dependable energy reserves.
Powerful 130 kW Output
Its maximum power rating of 130 kW enables the system to support high-demand equipment, commercial loads and industrial energy-management applications.
Safe LiFePO4 Technology
Lithium Iron Phosphate battery chemistry provides strong thermal stability, dependable performance and improved safety for large-scale energy-storage applications.
High-Capacity Energy Storage
With 261 kWh of rated energy, the FORCE A261 supports demanding commercial and industrial applications that require substantial and dependable energy reserves.
Powerful 130 kW Output
Its maximum power rating of 130 kW enables the system to support high-demand equipment, commercial loads and industrial energy-management applications.
Safe LiFePO4 Technology
Lithium Iron Phosphate battery chemistry provides strong thermal stability, dependable performance and improved safety for large-scale energy-storage applications.
Intelligent Air Cooling
The integrated air-cooling system helps regulate internal operating temperatures, maintain stable performance and protect the battery during continuous operation.
Multi-Layer Safety Protection
Multi-Layer Safety Protection
Smart Communication and Monitoring
RS485, CAN and Ethernet communication support enables integration with energy-management systems and compatible commercial power equipment.
ITAWATT Technical Specifications
| Specification | Technical Data |
|---|---|
| Product Overview | |
| Product Name | ITAWATT FORCE A261 |
| Product Type | Commercial and Industrial Battery Energy Storage System |
| Backup Duration | Approximately 2 hours at 0.5C configuration |
| Battery Specifications | |
| Rated Energy | 261 kWh |
| Rated Capacity | 314 Ah |
| Battery Chemistry | Lithium Iron Phosphate (LiFePO₄) |
| Battery Configuration | 260S1P |
| Rated Battery Voltage | 832 V |
| Battery Voltage Range | 728–936 V |
| Maximum Power | 130 kW |
| Maximum Current | 157 A |
| Performance and Cooling | |
| Cooling Method | Intelligent Air Cooling |
| Maximum Cycle Efficiency | 90%–99% |
| Auxiliary Power Supply | Self-powered or externally powered |
| Protection and Safety | |
| Protection Rating | Optional IP54/IP55 |
| Corrosion-Resistance Rating | Optional C3/C4/C5 |
| Safety Functions | Water-ingress protection, fire protection and access-control alarm |
| Environmental Conditions | |
| Operating Humidity | 0%–100%, non-condensing |
| Operating Temperature | −30°C to 50°C, with derating above 45°C |
| Maximum Operating Altitude | 3,000 m |
| Communication | |
| Communication Interfaces | RS485 and CAN |
| Communication Protocol | Modbus TCP |
| Mechanical Specifications | |
| Cabinet Dimensions | 1178 × 1411 × 2043 mm |
| Dimensions with Lifting Rings and Rain Shield | 1828 × 1411 × 2127 mm |
| System Weight | ≤2.8 tonnes |
| Warranty | |
| Warranty | To be confirmed |
Advantages
Reduce Peak Electricity Costs
Strengthen Operational Continuity
Strengthen Operational Continuity
