ITAWATT Force L261
L261
832 V
261 kWh
IP55
Lithium Iron Phosphate (LiFePO₄)
ITAWATT Force A261 is a high-capacity commercial and industrial battery energy storage system designed for businesses, solar projects, industrial parks, farms, power stations and backup power applications. With 261 kWh battery capacity, 125 kW active power output and intelligent air cooling, it helps store solar energy, manage peak loads, support backup power and improve energy reliability for demanding commercial environments.
ITAWATT Force L261
L261
261 kWh
IP55
832 V
Lithium Iron Phosphate (LiFePO₄)
ITAWATT Force A261 is a high-capacity commercial and industrial battery energy storage system designed for businesses, solar projects, industrial parks, farms, power stations and backup power applications. With 261 kWh battery capacity, 125 kW active power output and intelligent air cooling, it helps store solar energy, manage peak loads, support backup power and improve energy reliability for demanding commercial environments.
Features
High-Capacity Energy Storage
261 kWh storage capacity supports commercial energy backup, solar self-consumption and peak-load management.
Commercial & Industrial Power Support
Designed for industrial parks, farms, villas, power stations and business energy-storage projects.
Intelligent Air Cooling System
Maintains stable operating temperature and supports reliable long-term system performance.
High-Capacity Energy Storage
261 kWh storage capacity supports commercial energy backup, solar self-consumption and peak-load management.
Commercial & Industrial Power Support
Designed for industrial parks, farms, villas, power stations and business energy-storage projects.
Intelligent Air Cooling System
Maintains stable operating temperature and supports reliable long-term system performance.
Smart Energy Management
Supports anti-backflow, black start, peak shaving, valley filling and photovoltaic priority operation.
Advanced Safety Protection
Advanced Safety Protection
Advanced Safety Protection
Supports optional PV side and STS configuration for solar storage, diesel storage and grid-connected applications.
ITAWATT Technical Specifications
| Specification | Technical Data |
|---|---|
| Product Name | ITAWATT Force A261 |
| Product Type | Commercial & Industrial Battery Energy Storage System |
| Model | 125 kW / 261 kWh |
| Battery Chemistry | LiFePO4 Lithium Iron Phosphate |
| Cell Specification | 3.2 V / 314 Ah |
| Battery Configuration | 260S1P |
| Battery Capacity | 261 kWh |
| Max Battery Power | 100 kW |
| Max Current | 157 A |
| Battery Rated Voltage | 832 V |
| Battery Voltage Range | 728–936 V |
| AC Max Power | 137 kVA |
| Active Power | 125 kW |
| Rated AC Voltage | 400 V |
| Rated AC Current | 180 A |
| AC Voltage Range | 320–460 V |
| Rated Frequency | 50 / 60 Hz |
| Frequency Range | 45–55 / 55–65 Hz |
| THDI | <3% |
| Power Factor | 1.0, adjustable from 0.8 leading to 0.8 lagging |
| AC System | 3 Phase 4 Wires |
| Overload Capability | 110% |
| Solar Side | Optional |
| PV Max Power | 100 kW, 50 kW × 2 |
| PV High Voltage Side Voltage | 560–1000 V |
| PV High Voltage Side Current | 160 A |
| PV Low Voltage Side Voltage | 500–900 V |
| PV Low Voltage Side Current | 200 A |
| STS Function | Optional |
| STS Power | 200 kW |
| STS Voltage | 400 V, 50 / 60 Hz |
| STS Overload Power | 110% |
| Switching Time | <20 ms |
| Functional Strategy | Anti-backflow and black start |
| Operation Modes | Peak shaving, valley filling, electricity price peak-valley arbitrage, photovoltaic priority, wind power priority and off-grid power support |
| Operation Scenarios | Photovoltaic and diesel storage, wind and diesel storage, wind and photovoltaic diesel storage, charging station + energy storage and on-grid electricity selling |
| Cabinet Size | 1696 × 1408 × 2055 mm |
| Weight | ≤2.7 T |
| Maximum Cycle Efficiency | >90% |
| Protection Rating | IP55 |
| Auxiliary Power Supply | Self-powered / externally powered |
| Corrosion Resistance Rating | C3 / C5 |
| Operating Humidity | 0–100%, non-condensing |
| Operating Temperature | −30°C to 50°C, derating above 45°C |
| Maximum Operating Altitude | 2000 m |
| Cooling Method | Intelligent Air Cooling |
| Fire Safety Configuration | Smoke detector, heat detector, gas-based fire extinguishing system, pressure relief valve, pack-level fire protection, cluster-level fire protection, water-based fire protection and automatic pressure relief |
| Communication | Ethernet, RS485, CAN |
| Communication Protocol | Modbus TCP |
Advantages
Seamless Backup Switching
Helps maintain power continuity during grid instability, with optional STS support for fast switching and critical load protection.
Intelligent Air Cooling
Maintains stable battery performance through efficient air-cooling design, helping improve operating reliability and service life.
Intelligent Air Cooling
Maintains stable battery performance through efficient air-cooling design, helping improve operating reliability and service life.
Smart Monitoring & Safety
Built with intelligent monitoring, voltage/current protection, temperature control, fire safety protection, and reliable system communication.
