Itawatt 2.5kW Lithium Battery – Flow F2
Itawatt 2.5kW Lithium Battery – Flow F2
Features
Long-Life LiFePO₄ Technology
Stable lithium iron phosphate chemistry delivers dependable performance, excellent thermal stability and a cycle life of at least 6,000 cycles under specified conditions.
2.56 kWh Compact Storage
Stores 2.56 kWh of energy in a compact enclosure, making it suitable for essential residential loads and installations with limited space.
100A Charge and Discharge Capability
Supports maximum charging and discharging currents of 100A for efficient energy transfer within a correctly designed and compatible solar system.
Long-Life LiFePO₄ Technology
Stable lithium iron phosphate chemistry delivers dependable performance, excellent thermal stability and a cycle life of at least 6,000 cycles under specified conditions.
2.56 kWh Compact Storage
Stores 2.56 kWh of energy in a compact enclosure, making it suitable for essential residential loads and installations with limited space.
100A Charge and Discharge Capability
Supports maximum charging and discharging currents of 100A for efficient energy transfer within a correctly designed and compatible solar system.
Intelligent Inverter Communication
CAN, RS485 and RS232 communication ports allow the battery management system to exchange operating information with supported solar inverters.
Expandable up to 15 Units
Expandable up to 15 Units
Wi-Fi and Display Monitoring
Integrated Wi-Fi functionality and a display screen provide convenient access to essential battery status and operating information.
ITAWATT Technical Specifications
| Product Name | ITAWATT FLOW 2.5 |
|---|---|
| Model | ITA2.5 |
| Rated Energy | 2.56 kWh |
| Battery Capacity | 100Ah |
| Battery Chemistry | Lithium Iron Phosphate (LiFePO₄) |
| Nominal Voltage | 25.6V |
| Float Voltage | 29.2V |
| Equalization Voltage | 28V |
| Discharge Cut-Off Voltage | 22.4V |
| Maximum Charge Current | 100A |
| Maximum Discharge Current | 100A |
| Maximum C-Rate | 1C |
| Dimensions | 410 × 370 × 155 mm |
| Net Weight | 25.3 kg |
| Maximum Parallel Connection | Up to 15 batteries |
| Communication Ports | CAN / RS485 / RS232 |
| Charging Temperature | 0°C to 55°C |
| Discharging Temperature | -10°C to 55°C |
| Cycle Life | ≥6,000 cycles at 80% DoD, 0.5C and 25°C |
| Monitoring Functions | Wi-Fi and display screen |
| Documentation / Certifications | CE, UN38.3 and MSDS |
| Warranty | 5 Years |
Advantages
Reliable Backup for Essential Loads
Better Use of Solar Energy
Better Use of Solar Energy
